| Item | LT17/350+YB150+SG500 | LT19/250+YB150+SG500 |
| Drawing materials | Parkerising steel wire,stainless steel wire,gavanized zinc iron wire,copper wire | |
| Inlet wire tensile strength | ≤1250Mpa | |
| Drawing drafts | 17drafts | 19drafts |
| Max.inlet diameter | Φ3.50mm | Φ2.20mm |
| Min.outlet diameter | Φ0.80mm | Φ0.30mm |
| Motor power | 45/55KW | 22/30KW |
| 150 flattening machine | Super hard roller,recyclable wzter cooling system inside,slightly adjust compression by hand | |
| Specification | Section width/thickness ≤2.0 | |
| Flattening wire tolerance | Flattening wire thickness ±0.005mm | |
| Drawing speed | ≥450m/min | |
| Steel wire linearity | With wire straightener,coil diameter of finished wire is stable and adjustable,slove twisting problem. | |
| Take up mode | I spool take up machine,precisley lay and arrange wire | |
| Control mode | AC frequency invert+PLC+man machine interface,complete digital logic control | |
